BEAM SAW PP-330
Technician Data
| Model | PP-330 |
| Automation Grade | Automatic |
| Power | 15 kw |
| Brand | Nanxing India |
| Weight | 5500 kg |
| Saw Blade Diameter | 400 mm |
| Voltage | 415 v |
| Cutting Capacity | 3200 mm |
| Spindle Speed | 5000 rpm |
| Saw Carriage Speed | 120 m/min |
| Table Material | Steel |
- Pressure beam automatically self-adjusted according to the total height of panels, to shorten the travel range, hence higher efficiency.
- Saw carriage automatically moved to fit based on the width of panel, reduces travel distance.
- Both main saw and scoring saw with independent movements of up and down, also main saw automatically self-adjusted minimizing the lifting height for efficiency besides making best finish.The setting of the scoring saw blade to the main saw is carried out via the operating terminal.
- Scoring saw movements of up and down, as well as front and back, adjustable by software offering intelligent, fast, and easy elements.
- Quick exchange of main saw blade, ideal design for operator.
- Device fixed within saw carriage to push from side of board when running to cut, even for thin and soft board, at the same time to guide alignment for perfect square cut.
- Powerful software so easy to use, including managing the work process with detailed reports, simulating cutting patterns, showing any error message, printing bar code and many more advantages, also user friendly HMI, making whole machine much reliable.
